- Full Carbon frame with 160mm travel, front and rear
- 55Nm Bosch Performance Line SX Light drive unit; integrated (non removable) 400Wh battery
- 250Wh PowerMode range extender available separately
- Marzocchi Z1 fork and Bomber air shock
- Shimano Deore 12 speed and 4-piston brakes
- Expert TRII wheelset; 29" front and rear, Tubeless ready (tubeless tape and valves not included)- can run a mullet setup
- Lightweight carbon eMTB frame, powered by Bosch Performance Line SX drive unit and integrated 400Wh battery (non removable). A 250Wh battery extender is available separately. Marzocchi Z1 fork and Bomber air shock, Shimano Deore 12 speed and Shimano 4-piston brakes, Expert TRII wheelset; 29" front and rear (can be swapped to mullet using flip chip)
The eOne-Sixty SL 6000 is trail and enduro ready offering the perfect blend of price and performance. Combining our latest 160 mm travel carbon eMTB frame with the compact, lightweight Bosch Performance Line SX drivetrain to create a fun to ride e-enduro with almost human powered handling and a powerful 55 Nm of assistance to kick in when needed. If you're the type of rider who likes to pedal hard and use the assistance for maximum fun on the trail the eOne-Sixty SL is the bike for you. It represents a new breed of e-mountain bike, combining the poise of an unassisted bike with the power of a Bosch SX drive unit to help you ride further and faster. With a lightweight full carbon frame, 160mm of well balanced travel and a build that blends hard hitting performance with low weight, it blurs the line between conventional and assisted riding. Assistance is courtesy of the latest compact Bosch Performance Line SX motor with 55Nm and a fully integrated 400 Wh battery, a 250Wh range extender can be purchased separately. Approx overall weight 19.5kg. Lifetime frame warranty (category 4).
Specification
Frame
- CF4; full carbon; 160mm travel; fixed battery; Tapered head tube, 148 x 12mm axle standard. Max. tyre size 29" x 2.6"
Motor
- Bosch Performance Line SX
Battery
- Bosch CompactTube (CPT); 400Wh
Battery Capacity
- 400Wh
eBike Display
- Bosch Purion 400
Mode Switch
- Bosch Mini Remote
Shock
- Marzocchi Bomber Air
Fork
- Marzocchi Z1 eMTB; Air; 160mm travel; Tapered; 44mm fork offset; 29x2.6" max. tyre size
Gears
- 12
Shifters
- Shimano Deore
Rear Derailleur
- Shimano Deore
Bottom Bracket
- attached
Chain
- Shimano Deore M6100
Chainset
- FSA 1x Alloy Spider + Mega Tooth steel chain ring; 34 teeth. FSA CK-220 wide E-Bike Forged Crankset; 165mm for all sizes
Cassette
- Shimano Deore; 10-51 teeth; 12 speed
Brake Lever
- Shimano Deore
Front Brake
- Shimano Deore 4 piston hydraulic disc caliper with Shimano RT64, 220mm rotor
Rear Brake
- Shimano Deore 4 piston hydraulic disc caliper with Shimano RT64, 200mm rotor
Grip
- Merida Expert EC
Handlebar
- Merida Expert eTR; 780mm wide; XS,S 20mm rise ; M,L,XL 30mm rise
Stem
- Merida Expert eTR II; aluminium; 35 DSH; 0 ASD; Supernova mount. 40 mm all sizes
Head Set
- Acros ICR Merida integrated neck with Blocklock
Pedal
- VP VP-532
Saddle
- Merida Comp SL; 28% recycled material; V-mount; incl. Merida minitool
Seat Post
- Merida Comp TR III; 34.9mm diameter; 0mm lay back; XS: 125mm travel - S: 150mm travel- M/L/XL: 200mm travel - XL: 230mm travel
Wheel Size
- 29" / 27.5"
Rims
- Merida Expert TR II; 28mm inner rim width; aluminium; Tubeless ready (tubeless tape and valves not included); front 29"; rear 29"
Spokes
- Black stainless
Front Hub
- Shimano TC500; 15x100mm; 32 spoke; Centerlock
Rear Hub
- Shimano TC500; 12x148mm; 32 spoke; Centerlock with Merida Expert TR axle; including removeable lever, 6/4mm allen key
Front Tyre
- Maxxis Assegai; 29x2.5"; kevlar bead; TR EXO+ 3C MaxxGrip
Rear Tyre
- Maxxis Minion DHR II; 29x2.4"; kevlar bead; TR EXO+ 3C MaxxTerra
Colour
- Glossy Heritage Red
Season
- 2025
