| COLOUR |
Gloss dune tan yellow with matte black |
CASSETTE |
SRAM XS 1270, T-Type, 10-52T, 12 speed |
| FRAME |
Uni-directional carbon mainframe, tapered head tube, internal cable routing, 6061 Alloy swing arm, Shape.it Link V2 and 12mm x 148mm Boost dropouts |
CHAIN |
SRAM Eagle 70 |
| FORK |
RockShox ZEB Select, 160mm travel, 44mm offset, DebonAir, Charger RC damper, Fast Black coating, tapered steerer, 110mm x 15mm Boost, Maxle stealth |
CRANKSET |
Whyte 155mm ISIS arms, SRAM direct mount 36T chainring, T-Type |
| REAR SHOCK |
RockShox Deluxe Select R, DebonAir, Fast Black coating, adjustable rebound, custom tuned for Whyte |
BOTTOM BRACKET |
N/A |
| HEADSET |
Token TK19506 1/8in upper and 1.5in lower with sealed bearings |
SEATPOST |
TranzX +RAD 34.9mm, adjustable, size-specific drop (size S: 150mm travel; size M: 170mm travel; sizes L/XL: 200mm travel) |
| REAR HUB |
Alloy, e-bike specific, double sealed cartridge bearings, 12mm x 148mm Boost spacing, nine degree micro engagement four pawl, 32 hole |
SADDLE |
Whyte Custom |
| FRONT HUB |
Alloy, double sealed cartridge bearings, 12mm x 100mm thru-axle, 32 hole |
HANDLEBAR |
Whyte Custom 6061 alloy, 30mm rise, 35mm bar bore, 800mm wide |
| SPOKES |
14g stainless black, brass nipples |
STEM |
Whyte, 35mm Extension, 35mm Bar Bore |
| RIMS |
WTB ST Tough front rim, WTB HTZ Trail rear rim, 30mm internal |
GRIPS |
Whyte Enduro lock-on |
| TYRE |
Maxxis Assegai WT, TR, 29in x 2.5in 120TPI, EXO+ sidewall protection, 3C MaxxGrip, Dual Compound, folding bead, front; Maxxis Minion DHR 2 WT, TR, 29in x 2.4in 120TPI, Double Down casing, 3C MaxxTerra, dual compound, rear |
BRAKES FRONT |
SRAM DB8 Stealth, four piston with sintered metal pads, 220mm six bolt Centreline rotors |
| SHIFT LEVERS |
SRAM Eagle 70, 12 speed |
BRAKES REAR |
SRAM DB8 Stealth, four piston with sintered metal pads, 200mm six bolt Centreline rotors |
| FRONT MECH |
N/A |
BRAKE LEVERS |
SRAM DB8 Stealth |
| REAR MECH |
SRAM Eagle 90 T-Type mechanical, 12 speed |
