| COLOUR |
Midnight blue (gloss) |
CASSETTE |
SRAM XS 1275, T-Type, 10-52T, 12 speed |
| FRAME |
Uni-directional carbon mainframe and rear triangle, tapered head tube, internal cable routing, Shape.it Link V2 and 12mm x 148mm Boost dropouts |
CHAIN |
SRAM GX T-Type, 12 speed |
| FORK |
Fox Float 38 Performance Elite, 160mm travel, 44mm offset with Grip X2 damper custom tuned for Whyte, tapered steerer, 110mm x 15mm Boost, E-thru axle |
CRANKSET |
Whyte 155mm long ISIS crank arms, SRAM direct mount 36T chainring, T-Type |
| REAR SHOCK |
Fox Float X Performance Elite DPS, EVOL LV, 230 x 57.5mm, custom tuned for Whyte |
BOTTOM BRACKET |
N/A |
| HEADSET |
FSA No. 69/56/SRS, 1-1/8in upper and 1.5in lower with sealed angular contact bearing (ACB) cartridge bearings, with side entry internal routing |
SEATPOST |
KS Vantage dropper post with Southpaw remote lever, 34.9mm, external 30mm adjustment, frame size specific drop (size S 150mm drop; size M 170mm drop; sizes L-XL 200mm) |
| REAR HUB |
DT Swiss Hybrid H1900, 12mm x 148mm Boost spacing, SRAM XD steel driver, six bolt |
SEAT |
Whyte Custom |
| FRONT HUB |
DT Swiss Hybrid H1900, 110mm x 15mm Boost, six bolt |
BAR |
Race Face Turbine alloy, 35mm bar bore, 800mm wide, 35mm rise |
| SPOKES |
DT Swiss Elemental |
STEM |
Whyte, 35mm extension, 35mm bar bore |
| RIMS |
DT Swiss Hybrid H1900 |
GRIPS |
Whyte Enduro lock-on |
| TYRES |
Maxxis Assegai WT, TR, 29 x 2.5in 120TPI, EXO+ Sidewall Protection, 3C MaxxGrip, Dual Compound, folding bead (front); Maxxis Minion DHR 2 WT, TR, 29 x 2.4in 120TPI, Double Down Casing, 3C MaxxTerra, Dual Compound (rear) |
BRAKES FRONT |
Magura MT7 hydraulic disc brake, 203mm MDRC six bolt rotor |
| SHIFT LEVERS |
SRAM AXS Pod, right, MMX, 12 speed |
BRAKES REAR |
Magura MT7 hydraulic disc brake, 203mm MDRC six bolt rotor |
| FRONT MECH |
N/A |
BRAKE LEVERS |
Magura MT7 one finger lever |
| REAR MECH |
SRAM S1000 AXS Eagle, 12 speed |
PEDALS |
Fibre reinforced composite platform |
| WEIGHT |
24.2Kg (size M, without pedals, with innertubes) |
