| COLOUR |
Pearl yellow (gloss) |
CASSETTE |
Shimano CS-LG400, 11-50T, 11 speed Cues |
| FRAME |
6061 alloy, hydroformed T6 aluminium, multi-butted, custom drawn, tapered headtube, internal cable routing, Shape.it Link V2 and 12mm x 148mm Boost dropouts |
CHAIN |
KMC eGlide Sport, 11 speed Cues |
| FORK |
RockShox Psylo Gold, 160mm travel, DebonAir, Isolator RC damper, Fast Black coating, tapered steerer, 110 x 15mm Boost |
CRANKSET |
Whyte 160mm long ISIS crank arms, direct mount 36T chainring, T-Type |
| REAR SHOCK |
RockShox Deluxe Select R, DebonAir, Fast Black coating, adjustable rebound, custom tuned for Whyte |
BOTTOM BRACKET |
N/A |
| HEADSET |
Feimin FP-H886J 1-1/8in upper and 1.5in lower with sealed bearings |
SEATPOST |
TranzX +RAD adjustable dropper post, 30.9mm, frame size specific drop (size S 150mm drop; sizes M-L 170mm drop; size XL 200mm drop) |
| REAR HUB |
Shimano FH-TC600, Centre Lock, 12mm x 148mm Boost spacing, HG freehub, 32 hole |
SEAT |
Whyte Custom |
| FRONT HUB |
Shimano FH-TC500, Centre Lock, 15mm x 110mm Boost spacing, 32 hole |
BAR |
Whyte Custom 6061 alloy, 30mm rise, 35mm bar bore, 800mm wide |
| SPOKES |
Xin Da 14g stainless black, brass nipples |
STEM |
Whyte, 35mm extension, 35mm bar bore |
| RIMS |
WTB ST Tough (front), HTZ Trail (rear) 30mm internal width |
GRIPS |
Whyte Enduro lock-on |
| TYRES |
Maxxis Minion DHF, EXO casing, wire bead 29 x 2.5in (front and rear) |
BRAKES FRONT |
Shimano M4100 hydraulic disc brake, four piston, sintered metal pads, 220mm Centre Lock rotors |
| SHIFT LEVERS |
Shimano SL-U6000, 11 speed Cues |
BRAKES REAR |
Shimano M4100 hydraulic disc brake, four piston with sintered metal pads, 203mm Centre Lock rotors |
| FRONT MECH |
N/A |
BRAKE LEVERS |
Shimano M4100 |
| REAR MECH |
Shimano RD-U6000 GS, 11 speed Cues |
PEDALS |
Fibre reinforced composite platform |
| WEIGHT |
26.5Kg (size M, without pedals, with innertubes) |
|
