| COLOUR |
Dark cobalt blue (gloss) |
CASSETTE |
Shimano CS-HG500, 11-34T, 10 speed |
| FRAME |
6061 alloy, hydroformed T6 aluminium, multi-butted, tapered head tube, internal cable routing and custom Whyte dropouts |
CHAIN |
Shimano CN-HG54, 10 speed |
| FORK |
Whyte straight bladed 6061 alloy, alloy tapered steerer, internal cable routing, 12mm thru axle, flat mount with mudguard and mounting bosses |
CRANKSET |
Shimano FC-RX600, 170mm crank length (size XS and S)/172.5mm crank length (size M, L and XL), 46-30T chainrings |
| REAR SHOCK |
N/A |
BOTTOM BRACKET |
Shimano SM-BB52, 68/73mm |
| HEADSET |
No. 69 SRS, 1-1/8in upper and 1.5in lower with sealed cartridge bearings and front entry for cables |
SEATPOST |
Whyte 6061 alloy, 20mm offset, 27.2mm x 350mm, two bolt clamp |
| REAR HUB |
Alloy, double sealed cartridge bearings, 12mm x 142mm thru axle, Centre Lock, 32 hole |
SEAT |
Whyte Custom |
| FRONT HUB |
Alloy, double sealed cartridge bearings, 12mm x 100mm thru axle, Center Lock, 32 hole |
BAR |
Whyte, 6061 alloy, 70mm reach, 120mm drop, 10° flare 31.8mm x 400mm (sizes XS + S); 420mm (size M); 440mm (size L); 460mm (size XL) |
| SPOKES |
2.0mm, PG, black stainless, brass nipples |
STEM |
Whyte alloy, +-7° rise, 60mm length (sizes XS-S), 70mm (sizes M-XL) |
| RIMS |
23mm internal width, tubeless ready, 32 hole |
GRIPS |
Whyte anti-slip, ‘cross bar tape |
| TYRES |
Maxxis Reaver Tanwall 700 x 45c, EXO wire bead (front and rear) |
BRAKES FRONT |
Shimano GRX BR-RX400 hydraulic disc brake, Flat Mount, internal routing, 180mm rotor |
| SHIFT LEVERS |
Shimano GRX ST-RX400, 10 speed |
BRAKES REAR |
Shimano GRX BR-RX400 hydraulic disc brake, Flat Mount, internal routing, 160mm rotor |
| FRONT MECH |
Shimano GRX RD-RX400, 10 speed |
BRAKE LEVERS |
Shimano GRX ST-RX600 hydraulic |
| REAR MECH |
Shimano GRX RD-RX400, Shadow Plus, 10 speed |
PEDALS |
Fibre reinforced composite platform |
| WEIGHT |
TBC |
